M3645 300A Regen M3713 Power Supply M3728 Precharge

M3645 Line Regen

  • 208 - 600VAC support with 50/60Hz auto select
  • Replaces braking resistor solution
  • Over 99% efficient
  • Interactive digital display
  • Simple hook-up with no software setup
  • Integrated filtering and surge suppression
  • Parallel additional modules for higher current (Consult Bonitron for more than 2 total)
  • 150% overload

M3712 Single Phase Power Supply

  • Integrated precharge
  • Diagnostic indicators
  • Power single or multiple 3-phase drives from single phase source
  • No derating of VFD for single phase operation
  • Added bus capacitance and filtering for cooler running drives
  • Soft start-up to drives for increased reliability
  • Line Reactor recommended. Available through Bonitron

M3728 Precharge Module

  • Nema 1 Construction
  • Optional battery undervoltage protection
  • Controlled load disconnect
  • Self-protects from overloads
  • Allows use of diode rectifiers in case
    SCR rectifiers will not function
  • Allows use of regenerative power
    supplies without internal precharge
