SOLUTIONS FOR ROCKWELL AUTOMATION ALLEN-BRADLEY® DRIVES

Allen-Bradley Logo

As an Encompass Partner, Bonitron strives to offer only the best solutions for Rockwell Automation Allen Bradley Drives. Select your drive series below to match Bonitron Braking Transistors, Resistors, Line Regeneration Units, or Single Phase Power Supplies with your drive. DC bus connections are needed to connect a Bonitron transistor, line regen or power supply. Explore the rest of our AC drive accessory products as well by selecting a category from our product groups below.

Don't forget, Bonitron is the source for 1336 Legacy Solutions, including the 1336-MOD, 1336R, and 1336-W.

Please select your drive to show the table to match your drive to our Bonitron products:

1336 Series

The M3452 Complete Braking Kits include both a braking Transistor and Resistor in one conveinient enclosure. This reduces the amount of wiring necessary between two separate components and allows for a quicker installation, while maximizing production up-time.

M3452 Combo

Brochure | User Manual

Rockwell Bonitron
1336 Series Model Number Peak kW Peak HP Cont. Watts Ohms Dimensions
(H" x W" x D")
230 - 240 VAC | 375VDC Setpoint
1336-MOD-KA005 M3452-L3B-R030 4.7 kW 6.3 HP 600 W 30 Ω 18.25" x 9.50" x 8.50"
1336-MOD-KA010 M3452-L9C-R015 9.4 kW 12.6 HP 1800 W 15 Ω 18.25" x 11.50" x 10.50"
1336-MOD-KA050 M3452-L75B7-A* 28.4 kW 37.5 HP 2800 W 2.7 Ω 17.75" x 7.00" x 8.10"
1336-MOD-KA050 M3775RK-L030A 28.4 kW 37.5 HP 2800 W 2.7 Ω 11.50" x 29.00" x 18.00"
460 - 480 VAC | 750VDC Setpoint
1336-MOD-KB005 M3452-H9C-R108 5.2 kW 7.0 HP 1800 W 108 Ω 18.25" x 11.50" x 10.50"
1336-MOD-KB010 M3452-H9C-R050 11.3 kW 15.1 HP 1800 W 50 Ω 18.25" x 11.50" x 10.50"
1336-MOD-KB050 M3575T-H75* 56 kW 75 HP 5600 W 10 Ω 12.75" x 4.00" x 8.70"
1336-MOD-KB050 M3775RK-H075A 56 kW 75 HP 5600 W 10 Ω 11.50" x 29.00" x 18.00"
575 - 600 VAC | 940VDC Setpoint
1336-MOD-KC005 M3452-C9C-R108 8.2 kW 11.0 HP 1800 W 108 Ω 18.25" x 11.50" x 10.50"
1336-MOD-KC010 M3452-C9C-R050 17.7 kW 23.7 HP 1800 W 50 Ω 18.25" x 11.50" x 10.50"
1336-MOD-KC050 M3452-C75B7-A* 56 kW 75 HP 5600 W 15.6 Ω 17.75" x 7.00" x 8.10"
1336-MOD-KC050 M3775RK-C075A 56 kW 75 HP 5600 W 15.6 Ω 11.50" x 29.00" x 18.00"

* Requires separate chopper and resistor

The M3645 is used as a regenerative brake. The M3645P is a regenerative DC bus power supply.

M3645P Regen Power Supply

M3645P
Regen Power Supply

M3645 Line Regen

M3645
Line Regen

Rockwell Bonitron
1336R Series Line Regeneration
M3645		 Regenerative DC Bus Power Supplies
3-Phase with Precharge 3-Phase without Precharge
380 - 415 VAC Drives
1336R-VB048 M3645-E050-M11-D N/A M3645P-E050-M11-D
1336R-VB078 M3645-E100-M12-D N/A M3645P-E100-M12-D
1336R-VB180 M3645-E225T-M15-D M3645P-E225T-M15-D-R M3645P-E225T-M15-D
460 - 480 VAC Drives
1336R-VB048 M3645-H050-M11-D N/A M3645P-H050-M11-D
1336R-VB078 M3645-H100-M12-D N/A M3645P-H100-M12-D
1336R-VB180 M3645-H225T-M15-D M3645P-H225T-M15-D-R M3645P-H225T-M15-D

Braking Transistors are used with AC drives to allow full power braking and eliminate overvoltage faults. This permits controlled braking and shortens motor stopping time. If DC bus overvoltage occurs, Braking Transistors shunt excess energy through an external braking resistor.

M3575T
Braking Transistor

M3452
Braking Transistor

Rockwell Bonitron
1336 Series Model Number Peak
HP		 Peak
Current		 Cont. Current Min. Ohm Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
1336-WA018 M3575T-L60 30 HP 30 A 15 A 6.25 Ω 12.75" x 4.00" x 7.70"
1336-WA070 M3452-L200K6-R7 100 HP 200 A 200 A 1.9 Ω 20.00" x 7.12" x 10.50"
1336-WA115 M3452-L600K6-R7 300 HP 600 A 300 A 1.25 Ω 20.00" x 7.12" x 10.50"
460 - 480 VAC | 750VDC Setpoint
1336-WB009 M3575T-H75 75 HP 75 A 19 A 10 Ω 12.75" x 4.00" x 7.70"
1336-WB035 M3575T-H150 150 HP 150 A 38 A 5 Ω 17.75" x 5.50" x 8.00"
1336-WB110 M3575T-H600 600 HP 600 A 155 A 1.25 Ω 17.75" x 5.50" x 8.00"
575 - 600 VAC | 940VDC Setpoint
1336-WC009 M3452-C75B7-A 95 HP 75 A 75 A 13 Ω 17.75" x 7.00" x 8.10"
1336-WC035 M3452-C75B7-A 95 HP 75 A 75 A 13 Ω 17.75" x 7.00" x 8.10"
1336-WC085 M3452-C600K6-R7 760 HP 600 A 300 A 1.6 Ω 20.00" x 7.12" x 10.50"

Note: Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections are needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Feel free to call Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

PowerFlex® 4M
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
0 - 3.3 HP 0 - 20% M3675T-L10 10 A 2 A 38 Ω 7.00" x 2.06" x 6.75"
0 - 3.3 HP 20 - 50% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
0 - 3.3 HP 50 - 100% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 0 - 20% M3575T-L15 15 A 3.8 A 25 Ω 12.75" x 3.00" x 8.70"
3.3 - 5 HP 20 - 50% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 0 - 20% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
5 - 10 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 15 HP 0 - 20% M3575T-H30 30 A 7.75 A 5 Ω 12.75" x 3.00" x 8.70"
10 - 15 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 15 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

PowerFlex® 40
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
0 - 3.3 HP 0 - 20% M3675T-L10 10 A 2 A 38 Ω 7.00" x 2.06" x 6.75"
0 - 3.3 HP 20 - 50% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
0 - 3.3 HP 50 - 100% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 0 - 20% M3575T-L15 15 A 3.8 A 25 Ω 12.75" x 3.00" x 8.70"
3.3 - 5 HP 20 - 50% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 0 - 20% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
5 - 10 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
10 - 20 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
575 - 600 VAC | 940VDC Setpoint
10 - 20 HP 0 - 20% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 20 - 50% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

PowerFlex® 400

Click button below to see product table for your drive.

Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
0 - 3.3 HP 0 - 20% M3675T-L10 10 A 2 A 38 Ω 7.00" x 2.06" x 6.75"
0 - 3.3 HP 20 - 50% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
0 - 3.3 HP 50 - 100% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 0 - 20% M3575T-L15 15 A 3.8 A 25 Ω 12.75" x 3.00" x 8.70"
3.3 - 5 HP 20 - 50% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 0 - 20% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
5 - 10 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
10 - 20 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
20 - 25 HP 0 - 20% M3575T-L125 125 A 32 A 3 Ω 17.75" x 5.50" x 8.00"
20 - 25 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
20 - 25 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
25 - 40 HP 0 - 20% M3575T-L125 125 A 32 A 3 Ω 17.75" x 5.50" x 8.00"
25 - 40 HP 20 - 50% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
25 - 40 HP 50 - 100% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 0 - 20% M3575T-L150 150 A 38 A 2.5 Ω 17.75" x 5.50" x 8.00"
40 - 50 HP 20 - 50% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 50 - 100% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 0 - 20% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
15 - 40 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 0 - 20% M3575T-E125 125 A 32 A 5 Ω 17.75" x 5.50" x 8.00"
40 - 65 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 50 - 100% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 0 - 20% M3575T-E150 150 A 38 A 4.1 Ω 17.75" x 5.50" x 8.00"
65 - 80 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-E200 200 A 51 A 3.1 Ω 17.75" x 7.00" x 8.00"
80 - 100 HP 20 - 50% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
80 - 100 HP 50 - 100% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 0 - 20% M3575T-E300 300 A 77 A 2 Ω 17.75" x 7.00" x 8.00"
100 - 160 HP 20 - 50% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 20 - 50% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
160 - 325 HP 20 - 50% M3452-E600K6 600 A 300 A 1.04 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 50 - 100% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
325 - 350 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
325 - 350 HP 20 - 50% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
325 - 350 HP 20 - 50% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
10 - 20 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 0 - 20% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
20 - 50 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 0 - 20% M3575T-H125 125 A 32 A 6 Ω 17.75" x 5.50" x 8.00"
50 - 80 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 50 - 100% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-H150 150 A 38 A 5 Ω 17.75" x 5.50" x 8.00"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
100 - 130 HP 0 - 20% M3575T-H200 200 A 51 A 3.75 Ω 17.75" x 7.00" x 8.00"
100 - 130 HP 20 - 50% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
100 - 130 HP 50 - 100% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 0 - 20% M3575T-H300 300 A 77 A 2.5 Ω 17.75" x 7.00" x 8.00"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 0 - 20% M3575T-H600 600 A 155 A 1.25 Ω 17.75" x 7.00" x 8.00"
200 - 400 HP 20 - 50% M3452-H600K6 600 A 300 A 1.25 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 50 - 100% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

* Requires external reactor. Reactor sold by Bonitron

PowerFlex® 70
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
20 HP 0 - 20% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
20 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
20 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
25 HP 0 - 20% M3575T-L125 125 A 32 A 3 Ω 17.75" x 5.50" x 8.00"
25 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
25 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
380 - 415 VAC | 620VDC Setpoint
30 - 40 HP 0 - 20% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
30 - 40 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
30 - 40 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
460 - 480 VAC | 750VDC Setpoint
40 - 50 HP 0 - 20% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
40 - 50 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
575 - 6000 VAC | 940VDC Setpoint
40 - 50 HP 0 - 20% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 20 - 50% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 50 - 100% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

Drive Power
(Nominal)		 Model Number Output Current Input Current
(AC RMS)		 Dimensions
(H x W x D)
208 - 240 VAC Drives
20 - 25 HP M3712-L030 100 A 175 A 20.00" x 7.12" x 10.30"
460 - 480 VAC Drives
40 - 50 HP M3712-H050 90 A 185 A 20.00" x 7.12" x 10.30"

Line Reactor Required. Available from Bonitron.

Drive Power
(Nominal)		 Precharge Model Number Output Current Dimensions
(H x W x D)
208 - 240 VAC Drives
20 - 25 HP No M3713DM-L150-K7 150 A 20.00" x 7.12" x 10.35"
20 - 25 HP Yes M3713SC-L150-K7 150 A 20.00" x 7.12" x 10.35"
460 - 480 VAC Drives
40 - 50 HP No M3713DM-H150-K7 150 A 20.00" x 7.12" x 10.35"
40 - 50 HP Yes M3713SC-H150-K7 150 A 20.00" x 7.12" x 10.35"
575 - 600 VAC Drives
40 - 50 HP No M3713DM-C075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 50 HP Yes M3713SC-C075-B5 75 A 17.75" x 5.50" x 7.80"
PowerFlex® 523, 525

Click button below to see product table for your drive.

Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
0 - 3.3 HP 0 - 20% M3675T-L10 10 A 2 A 38 Ω 7.00" x 2.06" x 6.75"
0 - 3.3 HP 20 - 50% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
0 - 3.3 HP 50 - 100% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 0 - 20% M3575T-L15 15 A 3.8 A 25 Ω 12.75" x 3.00" x 8.70"
3.3 - 5 HP 20 - 50% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 0 - 20% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
5 - 10 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
10 - 20 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 0 - 20% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
15 - 40 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
10 - 20 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 0 - 20% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
20 - 50 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
575 - 6000 VAC | 940VDC Setpoint
0 - 63 HP 0 - 20% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 20 - 50% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 50 - 100% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

Drive Power
(Nominal)		 Model Number Output Current Input Current
(AC RMS)		 Dimensions
(H x W x D)
208 - 240 VAC Drives
0 - 30 HP M3712-L030 100 A 175 A 20.00" x 7.12" x 10.30"
460 - 480 VAC Drives
0 - 30 HP M3712-H030 55 A 115 A 20.00" x 7.12" x 10.30"

Line Reactor Required. Available from Bonitron.

Drive Power
(Nominal)		 Precharge Model Number Output Current Dimensions
(H x W x D)
208 - 240 VAC Drives
0 - 7.5 HP No M3713DM-L030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 7.5 HP Yes M3713SC-L030-B5 30 A 17.75" x 5.50" x 7.80"
7.5 - 20 HP No M3713DM-L075-B5 75 A 17.75" x 5.50" x 7.80"
7.5 - 20 HP Yes M3713SC-L075-B5 75 A 17.75" x 5.50" x 7.80"
460 - 480 VAC Drives
0 - 15 HP No M3713DM-H030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 15 HP Yes M3713SC-H030-B5 30 A 17.75" x 5.50" x 7.80"
15 - 40 HP No M3713DM-L075-B5 75 A 17.75" x 5.50" x 7.80"
15 - 40 HP Yes M3713SC-H075-B5 75 A 17.75" x 5.50" x 7.80"
575 - 600 VAC Drives
40 - 50 HP No M3713DM-C075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 50 HP Yes M3713SC-C075-B5 75 A 17.75" x 5.50" x 7.80"
PowerFlex® 700, 700S

Click button below to see product table for your drive.

Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
230 - 240 VAC | 375VDC Setpoint
0 - 3.3 HP 0 - 20% M3675T-L10 10 A 2 A 38 Ω 7.00" x 2.06" x 6.75"
0 - 3.3 HP 20 - 50% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
0 - 3.3 HP 50 - 100% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 0 - 20% M3575T-L15 15 A 3.8 A 25 Ω 12.75" x 3.00" x 8.70"
3.3 - 5 HP 20 - 50% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
3.3 - 5 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 0 - 20% M3575T-L30 30 A 7.75 A 12.5 Ω 12.75" x 3.00" x 8.70"
5 - 10 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
5 - 10 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-L60 60 A 15 A 6.25 Ω 12.75" x 4.00" x 8.70"
10 - 20 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
20 - 25 HP 0 - 20% M3575T-L125 125 A 32 A 3 Ω 17.75" x 5.50" x 8.00"
20 - 25 HP 20 - 50% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
20 - 25 HP 50 - 100% M3452-L75B7 75 A 75 A 5 Ω 17.75" x 7.00" x 8.10"
25 - 40 HP 0 - 20% M3575T-L125 125 A 32 A 3 Ω 17.75" x 5.50" x 8.00"
25 - 40 HP 20 - 50% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
25 - 40 HP 50 - 100% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 0 - 20% M3575T-L150 150 A 38 A 2.5 Ω 17.75" x 5.50" x 8.00"
40 - 50 HP 20 - 50% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
40 - 50 HP 50 - 100% M3452-L150B7 150 A 150 A 2.5 Ω 17.75" x 7.00" x 8.10"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 0 - 20% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
15 - 40 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 0 - 20% M3575T-E125 125 A 32 A 5 Ω 17.75" x 5.50" x 8.00"
40 - 65 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 50 - 100% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 0 - 20% M3575T-E150 150 A 38 A 4.1 Ω 17.75" x 5.50" x 8.00"
65 - 80 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 50 - 100% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-E200 200 A 51 A 3.1 Ω 17.75" x 7.00" x 8.00"
80 - 100 HP 20 - 50% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
80 - 100 HP 50 - 100% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 0 - 20% M3575T-E300 300 A 77 A 2 Ω 17.75" x 7.00" x 8.00"
100 - 160 HP 20 - 50% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 50 - 100% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
160 - 325 HP 20 - 50% M3452-E600K6 600 A 300 A 1.04 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 50 - 100% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
325 - 350 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
325 - 350 HP 20 - 50% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
325 - 350 HP 50 - 100% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
350 - 440 HP 0 - 20% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
350 - 440 HP 20 - 50% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
350 - 440 HP 50 - 100% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
440 - 660 HP 0 - 20% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
440 - 660 HP 20 - 50% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
440 - 660 HP 50 - 100% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 0 - 20% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 20 - 50% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 50 - 75% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
10 - 20 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 0 - 20% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
20 - 50 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 0 - 20% M3575T-H125 125 A 32 A 6 Ω 17.75" x 5.50" x 8.00"
50 - 80 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 50 - 100% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-H150 150 A 38 A 5 Ω 17.75" x 5.50" x 8.00"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
100 - 130 HP 0 - 20% M3575T-H200 200 A 51 A 3.75 Ω 17.75" x 7.00" x 8.00"
100 - 130 HP 20 - 50% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
100 - 130 HP 50 - 100% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 0 - 20% M3575T-H300 300 A 77 A 2.5 Ω 17.75" x 7.00" x 8.00"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 0 - 20% M3575T-H600 600 A 155 A 1.25 Ω 17.75" x 7.00" x 8.00"
200 - 400 HP 20 - 50% M3452-H600K6 600 A 300 A 1.25 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 50 - 100% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
400 - 530 HP 0 - 20% M3452-H800K9 800 A 400 A 0.93 Ω 20.00" x 9.05" x 10.25"
400 - 530 HP 20 - 50% M3452-H800K9 800 A 400 A 0.93 Ω 20.00" x 9.05" x 10.25"
400 - 530 HP 50 - 100% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
530 - 800 HP 0 - 20% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
530 - 800 HP 20 - 50% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
530 - 800 HP 50 - 100% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 0 - 20% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 20 - 50% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 50 - 75% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
575 - 600 VAC | 940VDC Setpoint
0 - 63 HP 0 - 20% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 20 - 50% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 50 - 100% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 0 - 20% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 20 - 50% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 50 - 100% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
125 - 165 HP 0 - 20% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
125 - 165 HP 20 - 50% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
125 - 165 HP 50 - 100% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 0 - 20% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 20 - 50% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 50 - 100% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 0 - 20% M3452-C600K6 600 A 600 A 1.6 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 20 - 50% M3452-C600K6 600 A 600 A 1.6 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 50 - 100% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
500 - 660 HP 0 - 20% M3452-C800K9 800 A 400 A 1.2 Ω 20.00" x 9.05" x 10.25"
500 - 660 HP 20 - 50% M3452-C800K9 800 A 400 A 1.2 Ω 20.00" x 9.05" x 10.25"
500 - 660 HP 50 - 100% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
660 - 1000 HP 0 - 20% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
660 - 1000 HP 20 - 50% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
660 - 1000 HP 50 - 100% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 0 - 20% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 20 - 50% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 50 - 75% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
690 VAC | 1090VDC Setpoint
0 - 70 HP 0 - 20% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
0 - 70 HP 20 - 50% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
0 - 70 HP 50 - 100% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 0 - 20% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 20 - 50% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 50 - 100% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
145 - 200 HP 0 - 20% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
145 - 200 HP 20 - 50% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
145 - 200 HP 50 - 100% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 0 - 20% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 20 - 50% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 50 - 100% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 0 - 20% M3452-U600YK6 600 A 600 A 1.95 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 20 - 50% M3452-U600YK6 600 A 600 A 1.95 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 50 - 100% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
580 - 780 HP 0 - 20% M3452-U800YK9 800 A 400 A 1.4 Ω 20.00" x 9.05" x 10.25"
580 - 780 HP 20 - 50% M3452-U800YK9 800 A 400 A 1.4 Ω 20.00" x 9.05" x 10.25"
580 - 780 HP 50 - 100% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
780 - 1165 HP 0 - 20% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
780 - 1165 HP 20 - 50% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
780 - 1165 HP 50 - 100% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 0 - 20% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 20 - 50% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 50 - 75% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

* Requires external reactor. Reactor sold by Bonitron

Drive Power
(Nominal)		 Model Number Output Current Input Current
(AC RMS)		 Dimensions
(H x W x D)
208 - 240 VAC Drives
0 - 30 HP M3712-L030 100 A 175 A 20.00" x 7.12" x 10.30"
30 - 50 HP M3712-L050 160 A 285 A 20.00" x 7.12" x 10.30"
50 - 75 HP M3712-L075 290 A 550 A 25.00" x 10.00" x 10.20"
75 - 125 HP M3712-L125 360 A 670 A 32.10" x 14.00" x 12.20"
460 - 480 VAC Drives
0 - 30 HP M3712-H030 55 A 115 A 20.00" x 7.12" x 10.30"
30 - 50 HP M3712-H050 90 A 185 A 20.00" x 7.12" x 10.30"
50 - 75 HP M3712-H075 135 A 250 A 25.00" x 10.00" x 10.20"
75 - 125 HP M3712-H125 200 A 365 A 32.10" x 14.00" x 12.20"
125 - 225 HP (2x)M3712-H125 360 A 655 A (2x) 32.10" x 14.00" x 12.20"
225 - 335 HP (3x) M3712-H125 540 A 985 A (3x) 32.10" x 14.00" x 12.20"

Line Reactor Required. Available from Bonitron.

Drive Power
(Nominal)		 Precharge Model Number Output Current Dimensions
(H x W x D)
208 - 240 VAC Drives
0 - 7.5 HP No M3713DM-L030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 7.5 HP Yes M3713SC-L030-B5 30 A 17.75" x 5.50" x 7.80"
7.5 - 20 HP No M3713DM-L075-B5 75 A 17.75" x 5.50" x 7.80"
7.5 - 20 HP Yes M3713SC-L075-B5 75 A 17.75" x 5.50" x 7.80"
20 - 50 HP No M3713DM-L150-K7 150 A 20.00" x 7.12" x 10.35"
20 - 50 HP Yes M3713SC-L150-K7 150 A 20.00" x 7.12" x 10.35"
50 - 75 HP No M3713DM-L225-K7 225 A 20.00" x 7.12" x 10.35"
50 - 75 HP Yes M3713SC-L225-K7 225 A 20.00" x 7.12" x 10.35"
75 - 125 HP No M3713DM-L375-K10 375 A 20.00" x 10.00" x 10.50"
75 - 125 HP Yes M3713SC-L375-K10 375 A 20.00" x 10.00" x 10.50"
460 - 480 VAC Drives
0 - 15 HP No M3713DM-H030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 15 HP Yes M3713SC-H030-B5 30 A 17.75" x 5.50" x 7.80"
15 - 40 HP No M3713DM-L075-B5 75 A 17.75" x 5.50" x 7.80"
15 - 40 HP Yes M3713SC-H075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 100 HP No M3713DM-H150-K7 150 A 20.00" x 7.12" x 10.35"
40 - 100 HP Yes M3713SC-H150-K7 150 A 20.00" x 7.12" x 10.35"
100 - 150 HP No M3713DM-H225-K7 225 A 20.00" x 7.12" x 10.35"
100 - 150 HP Yes M3713SC-H225-K7 225 A 20.00" x 7.12" x 10.35"
150 - 250 HP No M3713DM-H375-K10 375 A 20.00" x 10.00" x 10.50"
150 - 250 HP Yes M3713SC-H375-K10 375 A 20.00" x 10.00" x 10.50"
250 - 450 HP No (2x) M3713DM-H375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
250 - 450 HP Yes (2x) M3713SC-H375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
450 - 675 HP No (3x) M3713DM-H375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
450 - 675 HP Yes (3x) M3713SC-H375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
575 - 600 VAC Drives
0 - 20 HP No M3713DM-C030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 20 HP Yes M3713SC-C030-B5 30 A 17.75" x 5.50" x 7.80"
40 - 50 HP No M3713DM-C075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 50 HP Yes M3713SC-C075-B5 75 A 17.75" x 5.50" x 7.80"
50 - 125 HP No M3713DM-C150-K7 150 A 20.00" x 7.12" x 10.35"
50 - 125 HP Yes M3713SC-C150-K7 150 A 20.00" x 7.12" x 10.35"
125 - 175 HP No M3713DM-C225-K7 225 A 20.00" x 7.12" x 10.35"
125 - 175 HP Yes M3713SC-C225-K7 225 A 20.00" x 7.12" x 10.35"
175 - 300 HP No M3713DM-C375-K10 375 A 20.00" x 10.00" x 10.50"
175 - 300 HP Yes M3713SC-C375-K10 375 A 20.00" x 10.00" x 10.50"
300 - 540 HP No (2x) M3713DM-C375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
300 - 540 HP Yes (2x) M3713SC-C375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
540 - 810 HP No (3x) M3713DM-C375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
540 - 810 HP Yes (3x) M3713SC-C375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
PowerFlex® 753, 755

Click button below to see product table for your drive.

Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
380 - 415 VAC | 620VDC Setpoint
0 - 5 HP 0 - 20% M3675T-E10 10 A 2 A 62 Ω 7.00" x 2.06" x 6.75"
0 - 5 HP 20 - 50% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
0 - 5 HP 50 - 100% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 0 - 20% M3575T-E15 15 A 3.8 A 41.25 Ω 12.75" x 3.00" x 8.70"
5 - 8 HP 20 - 50% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
5 - 8 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 0 - 20% M3575T-E30 30 A 7.75 A 20.5 Ω 12.75" x 3.00" x 8.70"
8 - 15 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
8 - 15 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 0 - 20% M3575T-E75 75 A 19 A 8.25 Ω 12.75" x 4.00" x 8.70"
15 - 40 HP 20 - 50% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
15 - 40 HP 50 - 100% M3452-E75B7 75 A 75 A 8.27 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 0 - 20% M3575T-E125 125 A 32 A 5 Ω 17.75" x 5.50" x 8.00"
40 - 65 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
40 - 65 HP 50 - 100% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 0 - 20% M3575T-E150 150 A 38 A 4.1 Ω 17.75" x 5.50" x 8.00"
65 - 80 HP 20 - 50% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
65 - 80 HP 50 - 100% M3452-E150B7 150 A 150 A 4.13 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-E200 200 A 51 A 3.1 Ω 17.75" x 7.00" x 8.00"
80 - 100 HP 20 - 50% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
80 - 100 HP 50 - 100% M3452-E200K6 200 A 200 A 3.1 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 0 - 20% M3575T-E300 300 A 77 A 2 Ω 17.75" x 7.00" x 8.00"
100 - 160 HP 20 - 50% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
100 - 160 HP 50 - 100% M3452-E300K6 300 A 300 A 2.07 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
160 - 325 HP 20 - 50% M3452-E600K6 600 A 300 A 1.04 Ω 20.00" x 7.12" x 10.50"
160 - 325 HP 50 - 100% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
325 - 350 HP 0 - 20% M3575T-E600 600 A 155 A 1.1 Ω 17.75" x 7.00" x 8.00"
325 - 350 HP 20 - 50% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
325 - 350 HP 50 - 100% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
350 - 440 HP 0 - 20% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
350 - 440 HP 20 - 50% M3452-E800K9 800 A 400 A 0.78 Ω 20.00" x 7.12" x 10.50"
350 - 440 HP 50 - 100% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
440 - 660 HP 0 - 20% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
440 - 660 HP 20 - 50% M3452-E1200K10 1200 A 600 A 0.52 Ω 20.00" x 10.00" x 10.50"
440 - 660 HP 50 - 100% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 0 - 20% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 20 - 50% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
660 - 885 HP 50 - 75% M3452-E1600M14 1600 A 1200 A 0.39 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
460 - 480 VAC | 750VDC Setpoint
0 - 6.5 HP 0 - 20% M3675T-H10 10 A 2 A 75 Ω 7.00" x 2.06" x 6.75"
0 - 6.5 HP 20 - 50% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
0 - 6.5 HP 50 - 100% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 0 - 20% M3575T-H15 15 A 3.8 A 50 Ω 12.75" x 3.00" x 8.70"
6.5 - 10 HP 20 - 50% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
6.5 - 10 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 0 - 20% M3575T-H30 30 A 7.75 A 25 Ω 12.75" x 3.00" x 8.70"
10 - 20 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
10 - 20 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 0 - 20% M3575T-H75 75 A 19 A 10 Ω 12.75" x 4.00" x 8.70"
20 - 50 HP 20 - 50% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
20 - 50 HP 50 - 100% M3452-H75B7 75 A 75 A 10 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 0 - 20% M3575T-H125 125 A 32 A 6 Ω 17.75" x 5.50" x 8.00"
50 - 80 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
50 - 80 HP 50 - 100% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 0 - 20% M3575T-H150 150 A 38 A 5 Ω 17.75" x 5.50" x 8.00"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
80 - 100 HP 20 - 50% M3452-H150B7 150 A 150 A 5 Ω 17.75" x 7.00" x 8.10"
100 - 130 HP 0 - 20% M3575T-H200 200 A 51 A 3.75 Ω 17.75" x 7.00" x 8.00"
100 - 130 HP 20 - 50% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
100 - 130 HP 50 - 100% M3452-H200K6 200 A 200 A 3.8 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 0 - 20% M3575T-H300 300 A 77 A 2.5 Ω 17.75" x 7.00" x 8.00"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
130 - 200 HP 20 - 50% M3452-H300K6 300 A 300 A 2.5 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 0 - 20% M3575T-H600 600 A 155 A 1.25 Ω 17.75" x 7.00" x 8.00"
200 - 400 HP 20 - 50% M3452-H600K6 600 A 300 A 1.25 Ω 20.00" x 7.12" x 10.50"
200 - 400 HP 50 - 100% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
400 - 530 HP 0 - 20% M3452-H800K9 800 A 400 A 0.93 Ω 20.00" x 9.05" x 10.25"
400 - 530 HP 20 - 50% M3452-H800K9 800 A 400 A 0.93 Ω 20.00" x 9.05" x 10.25"
400 - 530 HP 50 - 100% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
530 - 800 HP 0 - 20% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
530 - 800 HP 20 - 50% M3452-H1200K10 1200 A 600 A 0.63 Ω 20.00" x 10.00" x 10.50"
530 - 800 HP 50 - 100% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 0 - 20% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 20 - 50% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
800 - 1060 HP 50 - 75% M3452-H1600M14 1600 A 1200 A 0.47 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
575 - 600 VAC | 940VDC Setpoint
0 - 63 HP 0 - 20% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 20 - 50% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
0 - 63 HP 50 - 100% M3452-C75B7 75 A 75 A 12.5 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 0 - 20% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 20 - 50% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
63 - 125 HP 50 - 100% M3452-C150B7 150 A 150 A 6.3 Ω 17.75" x 7.00" x 8.10"
125 - 165 HP 0 - 20% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
125 - 165 HP 20 - 50% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
125 - 165 HP 50 - 100% M3452-C200K6 200 A 200 A 4.7 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 0 - 20% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 20 - 50% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
165 - 250 HP 50 - 100% M3452-C300K6 300 A 300 A 3.2 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 0 - 20% M3452-C600K6 600 A 600 A 1.6 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 20 - 50% M3452-C600K6 600 A 600 A 1.6 Ω 20.00" x 7.12" x 10.50"
250 - 500 HP 50 - 100% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
500 - 660 HP 0 - 20% M3452-C800K9 800 A 400 A 1.2 Ω 20.00" x 9.05" x 10.25"
500 - 660 HP 20 - 50% M3452-C800K9 800 A 400 A 1.2 Ω 20.00" x 9.05" x 10.25"
500 - 660 HP 50 - 100% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
660 - 1000 HP 0 - 20% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
660 - 1000 HP 20 - 50% M3452-C1200K10 1200 A 600 A 0.78 Ω 20.00" x 10.00" x 10.50"
660 - 1000 HP 50 - 100% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 0 - 20% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 20 - 50% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
1000 - 1340 HP 50 - 75% M3452-C1600M14 1600 A 1200 A 0.58 Ω 28.00" x 13.90" x 14.60"
Drive Power Duty Model Number Braking Current
(Peak)		 Braking Current
(RMS)		 Minimum
Resistance		 Dimensions
(H x W x D)
690 VAC | 1090VDC Setpoint
0 - 70 HP 0 - 20% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
0 - 70 HP 20 - 50% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
0 - 70 HP 50 - 100% M3452-U75YB7 75 A 75 A 14.5 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 0 - 20% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 20 - 50% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
70 - 145 HP 50 - 100% M3452-U150YB7 150 A 150 A 7.3 Ω 17.75" x 7.00" x 8.10"
145 - 200 HP 0 - 20% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
145 - 200 HP 20 - 50% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
145 - 200 HP 50 - 100% M3452-U200YK6 200 A 200 A 5.5 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 0 - 20% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 20 - 50% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
200 - 290 HP 50 - 100% M3452-U300YK6 300 A 300 A 3.6 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 0 - 20% M3452-U600YK6 600 A 600 A 1.95 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 20 - 50% M3452-U600YK6 600 A 600 A 1.95 Ω 20.00" x 7.12" x 10.50"
290 - 580 HP 50 - 100% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
580 - 780 HP 0 - 20% M3452-U800YK9 800 A 400 A 1.4 Ω 20.00" x 9.05" x 10.25"
580 - 780 HP 20 - 50% M3452-U800YK9 800 A 400 A 1.4 Ω 20.00" x 9.05" x 10.25"
580 - 780 HP 50 - 100% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
780 - 1165 HP 0 - 20% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
780 - 1165 HP 20 - 50% M3452-U1200YK10 1200 A 600 A 0.91 Ω 20.00" x 10.00" x 10.50"
780 - 1165 HP 50 - 100% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 0 - 20% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 20 - 50% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"
1165 - 1530 HP 50 - 75% M3452-U1600YM14 1600 A 1200 A 0.68 Ω 28.00" x 13.90" x 14.60"

Notes:
Contact Bonitron for Resistor sizing. Transistors are sized for 150% overload.
PowerFlex® 4M requires special attention when used with Bonitron M3712 or M3713 Power Supplies. Tables are a general guide only and selections should be verified by those purchasing equipment. DC bus connections needed to connect a Bonitron transistor, line regen or power supply. Confirm resistor ohm rating is higher than drive's min ohm if connecting directly to drive brake. Please contact Bonitron at 615-244-2825 to verify you have the best solution for your spec.

RAISE, ProposalWorks, and PowerFlex are registered Trademarks of Rockwell Automation.

* Requires external reactor. Reactor sold by Bonitron

Drive Power
(Nominal)		 Model Number Output Current Input Current
(AC RMS)		 Dimensions
(H x W x D)
460 - 480 VAC Drives
0 - 30 HP M3712-H030 55 A 115 A 20.00" x 7.12" x 10.30"
30 - 50 HP M3712-H050 90 A 185 A 20.00" x 7.12" x 10.30"
50 - 75 HP M3712-H075 135 A 250 A 25.00" x 10.00" x 10.20"
75 - 125 HP M3712-H125 200 A 365 A 32.10" x 14.00" x 12.20"
125 - 225 HP (2x)M3712-H125 360 A 655 A (2x) 32.10" x 14.00" x 12.20"
225 - 335 HP (3x) M3712-H125 540 A 985 A (3x) 32.10" x 14.00" x 12.20"

Line Reactor Required. Available from Bonitron.

Drive Power
(Nominal)		 Precharge Model Number Output Current Dimensions
(H x W x D)
460 - 480 VAC Drives
0 - 15 HP No M3713DM-H030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 15 HP Yes M3713SC-H030-B5 30 A 17.75" x 5.50" x 7.80"
15 - 40 HP No M3713DM-L075-B5 75 A 17.75" x 5.50" x 7.80"
15 - 40 HP Yes M3713SC-H075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 100 HP No M3713DM-H150-K7 150 A 20.00" x 7.12" x 10.35"
40 - 100 HP Yes M3713SC-H150-K7 150 A 20.00" x 7.12" x 10.35"
100 - 150 HP No M3713DM-H225-K7 225 A 20.00" x 7.12" x 10.35"
100 - 150 HP Yes M3713SC-H225-K7 225 A 20.00" x 7.12" x 10.35"
150 - 250 HP No M3713DM-H375-K10 375 A 20.00" x 10.00" x 10.50"
150 - 250 HP Yes M3713SC-H375-K10 375 A 20.00" x 10.00" x 10.50"
250 - 450 HP No (2x) M3713DM-H375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
250 - 450 HP Yes (2x) M3713SC-H375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
450 - 675 HP No (3x) M3713DM-H375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
450 - 675 HP Yes (3x) M3713SC-H375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
575 - 600 VAC Drives
0 - 20 HP No M3713DM-C030-B5 30 A 17.75" x 5.50" x 7.80"
0 - 20 HP Yes M3713SC-C030-B5 30 A 17.75" x 5.50" x 7.80"
40 - 50 HP No M3713DM-C075-B5 75 A 17.75" x 5.50" x 7.80"
40 - 50 HP Yes M3713SC-C075-B5 75 A 17.75" x 5.50" x 7.80"
50 - 125 HP No M3713DM-C150-K7 150 A 20.00" x 7.12" x 10.35"
50 - 125 HP Yes M3713SC-C150-K7 150 A 20.00" x 7.12" x 10.35"
125 - 175 HP No M3713DM-C225-K7 225 A 20.00" x 7.12" x 10.35"
125 - 175 HP Yes M3713SC-C225-K7 225 A 20.00" x 7.12" x 10.35"
175 - 300 HP No M3713DM-C375-K10 375 A 20.00" x 10.00" x 10.50"
175 - 300 HP Yes M3713SC-C375-K10 375 A 20.00" x 10.00" x 10.50"
300 - 540 HP No (2x) M3713DM-C375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
300 - 540 HP Yes (2x) M3713SC-C375-K10 675 A (2x) 20.00" x 10.00" x 10.50"
540 - 810 HP No (3x) M3713DM-C375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"
540 - 810 HP Yes (3x) M3713SC-C375-K10 1010 A (3x) 20.00" x 10.00" x 10.50"

News

Browse our recently overhauled ProposalWorks™ listing. Use the configurator to help determine the best product for your application.

Discover why many are using Bonitron Common Bus Diodes, as referenced in PowerFlex® AC Drives in Common Bus Configurations (Newer Version)

Discover why many are using Bonitron Common Bus Diodes, as referenced in PowerFlex® AC Drives in Common Bus Configurations

Additional Drive Solutions

AB/Bonitron Drive Schematic
Back to Top
